ShockWave 4Channel Amplifier 4x100WRms @ 4Ohm JD-4150SQ

ShockWave 4Channel Amplifier JD-4150SQ

Features

1) Full Range Class A/B Class design

2) Thermal, Overload, Speaker short protection

3) Variable Low pass filter

4) Variable High pass filter

5) Adjustable input sensitivity

6) RCA low lever inputs

7) Aluminum alloy heatsink



Specifications

1) 4 Ohm RMS power: 100Watts x 4

2) 2 Ohm RMS power: 150Watts x 4

3) 4 Ohm Bridged power: 250Watts x 2

4) Frequency response: 20Hz - 20Khz

5) S/N Ratio: > 90db

6) THD Rated: <0.2%

7) Input voltage: 200mV - 10V

8) Dimensions(LxWxH): 331x140x48mm
