5Channel

SD800.5 EVO6

SOUNDIGITAL
Κωδικός: SD800.5 EVO6
Άμεσα διαθέσιμο
Τιμή € 250,00
Ποσότητα
Προσθήκη στο καλάθι

General Specifications

+

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    800.5 EVO6 – 4 OHMS

    Power @ 4Ω: 4 x 100W RMS
    Power @ 8Ω: 4 x 66W RMS
    SUBWOOFER: 4Ω: 1 x 400W

    Bridge Power @ 8Ω: 2 X 200W RMS
    SUBWOOFER: 8Ω: N/A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Frequency Response (-3dB):

    80Hz ~ 25kHz
    SUBWOOFER: 5Hz ~ 80Hz

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Low Pass Filter (12dB/octave):

    80Hz

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    High Pass Filter (12dB/octave):

    80Hz

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Operating Voltage:

    9V ~ 16V

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    SNR:

    103.88dB
    SUBWOOFER: 102dB

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Input Sensitivity (RCA):

    0.2V ~ 2V

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Current Draw (music):

    39A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Current Draw (max.):

    78.7A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Total Efficiency:

    80%

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Damping Factor (@100Hz nominal impedance):

    200

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Power Cable:

    10mm² (7 AWG)

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Speaker Cable:

    1.5mm² (15 AWG) / 2.5mm² (13 AWG)

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Recommended Fuse (music):

    40A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Recommended Battery (minimum):

    60Ah

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Width:

    6.01" / 15,7 cm

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Lenght:

    4.52" / 11,7 cm

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Height:

    2.07" / 5,5 cm

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg') repeat;">

    Weight:

    0.74 kg / 1.63 lb
